Spezifikation
| PV-Eingang | |
|---|---|
| Max. PV-Eingangsleistung | 2600W max |
| PV-Eingangsspannungsbereich | 16-60VDC |
| Max PV-Eingangsspannung | 60VDC |
| PV-Eingangs-Spannungsbereich | 16-60VDC |
| Anzahl der MPPT-Kanäle | 4 |
| Anzahl der PV-Strings pro MPPT-Kanal | 1 |
| PV-Eingangsstrom | 20A Max |
| On-grid Anschluss | |
| AC-Nennausgangsleistung | 800W |
| Max. Ausgangsstrom | 3,5A Max |
| Nennausgangsspannung | 230V |
| AC-Netzfrequenz (Bereich*) | 50Hz/60Hz |
| Vielseitiger AC-Anschluss | |
| AC-Off-Grid-Nennausgangsleistung | 800W |
| Nennausgangsspannung | 230V |
| Max. Ausgangsstrom | 3,5A Max |
| Batterie-Spezifikationen | |
| Batterietyp | LiFePO4 |
| Batteriekapazität | 2048Wh |
| Max.Expansionskapazität | 8192Wh |
| Max. Ladeleistung | 2000W max |
| Nennspannung | 51.2V |
| Allgemein | |
| Lade-/Entladetemperaturbereich* | 0°C~ 55°C/-20°C~ 55°C |
| Abmessungen (B/T/H) | 406*255*290 mm |
| Gewicht | ≈24kg |
| Schutzniveau | IP66 |
| Benutzeroberfläche | LED & APP |
| WiFi/Buletooth | Unterstützt |
| Garantie | 10 Jahre |
| Zertifikate | VDE-AR-N 4105: 2018, TORErzeuger Type A, EN 50549, CE, IEC62109, IEC62619, IEC62477, Rohs, Reach, UN38.3 |
